Mfr.part#:	AIR-AP1562D-A-K9
Name:	AIR-AP1562D-A-K9 - Cisco Aironet 1562D Outdoor Access Point
Detail:	802.11ac Wave 2 Low-Profile Outdoor AP, Directional Antenna, A Regulatory Domain AIR-AP1562D-A-K9
Availability:	In Stock
Condition:	New
GTIN:	0882658905216 0882658905216 882658905216

AIR-AP1562D-A-K9

Shipping:

Free ground shipping within United States up to 10LBS

᛫ Items in stock will arrive within the estimated delivery time.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.

Accepting POs:

We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.

Payment:

Pay by Visa.
Pay with your Visa credit card.
Pay with your Discover Card.
Pay with your America Express.
Pay with your JCB.
Pay with your Wire Transfer.

Genuine Guarantee
Price Protection
Bulk Order Rebate
30 Day Return Policy

Laila Jones

Technical Customer Support

CHAT
EMAIL
WHATSAPP

(800) 870-9487

overview

specifications

resources

reviews

overview

Overview

AIR-AP1562D-A-K9 Overview

Cisco Aironet 1562D. Maximum data transfer rate: 1300 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s, Frequency band: 2.412 - 2.462, 5.28 - 5.32, 5.5 - 5.58, 5.66 - 5.7, 5.745 - 5.825 GHz. Security algorithms: AES, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, IPSec, LEAP, WPA, WPA2. WAN connection: Ethernet (RJ-45). AC input voltage: 44 - 57 V, Power consumption (typical): 25 W. Placement: Pole, Wall, Product colour: Grey, International Protection (IP) code: IP67

Cisco AIR-AP1562D-A-K9 Outdoor Access Point offers the latest 802.11ac Wave 2 functions in a rugged, low-profile housing that service providers and enterprises can deploy easily. Ideal for applications requiring rugged outdoor Wi-Fi coverage, the Cisco Aironet 1560 Series Access Points offer the latest IEEE 802.11ac Wave 2 radio standard in a compact, aesthetically pleasing, easy-to-deploy package.

Quick Specs

Table 1 shows the Quick Specs.

SKU	AIR-AP1562D-A-K9
Type	Wireless access point
Form Factor	External
Data Transfer Rate	1.3 Gbps
Compliant Standards	IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at
Wireless Protocol	802.11a/b/g/n/ac Wave 2
Power Over Ethernet (PoE)	PoE+
Wi-Fi Bands	2.4 GHz, 5 GHz

Product Details

Cisco AIR-AP1562D-A-K9 has these benefits:

①802.11ac Wave 2 radio

Provides up to 1.3-Gbps data rates with 3 x 3 Multiple Input, Multiple Output (MIMO) and up to three spatial streams.

②Multiuser MIMO (MU-MIMO)

Allows transmission of data to multiple 802.11ac Wave 2-capable clients simultaneously to improve client experience; prior to 802.11ac Wave 2, access points could transmit data to only one client at a time, typically referred to as single-user MIMO.

③Flexible deployment modes

Allows for deployment of the 1560 in a variety of ways including point -to-point and mesh networks; it can also be deployed with the Cisco Mobility Express Solution, which is ideal f or small to medium -sized deployments that supports multiple access points without a physical controller; all deployment modes are easy to set up and configure.

④Small Form-Factor Pluggable (SFP) port

Supports optical fiber-based network connectivity for remote locations.

Compare to Similar Items

Table 2 shows the comparison.

Product Name	AIR-AP1562D-A-K9	AIR-AP1562E-B-K9
Antenna	Internal	External
Data Transfer Rate	1.3 Gbps	1.3 Gbps
Wireless Protocol	802.11a/b/g/n/ac Wave 2	802.11a/b/g/n/ac Wave 2
Wi-Fi Bands	2.4 GHz, 5 GHz	2.4 GHz, 5 GHz
Power Over Ethernet (PoE)	PoE+	PoE+

Get More Information

Do you have any question about the AIR-AP1562D-A-K9?

Dual-band 802.11a/g/n/ac, Wave 2, internal directional antennas, A Regulatory Domain

2.4 GHz

5 GHz

Maximum data transfer rate: 1300 Mbit/s

IEEE 802.11ac, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at

AES, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, IPSec, LEAP, WPA, WPA2

Power over Ethernet (PoE)

Antennas quantity: 2 Internal Integrated antenna

Summary Description

Cisco Aironet 1562D, 1300 Mbit/s, 10,100,1000 Mbit/s, 2.412 - 2.462, 5.28 - 5.32, 5.5 - 5.58, 5.66 - 5.7, 5.745 - 5.825 GHz, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3at, 27 channels, 80 MHz

100% Low Price Guarantee

We offer high-quality network parts at wholesale prices that are guaranteed to be low.

What is the minimum price for the Cisco AIR-AP1562D-A-K9?

Click hereto find the lowest discounted price for AIR-AP1562D-A-K9.

Explore even more affordable prices for Wireless and Cisco products.

specifications

Specification

AIR-AP1562D-A-K9 Specification

AIR-AP1562D-A-K9 Specification
General
Device Type	Wireless access point
Ruggedized Design	Outdoor
Width	6.7 in
Depth	4.3 in
Height	9 in
Networking
Form Factor	External
Connectivity Technology	Wireless
Data Transfer Rate	1.3 Gbps
Data Link Protocol	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ac Wave 2
Network / Transport Protocol	L2TP, IPSec
Frequency Band	2.4 GHz, 5 GHz
Features	Auto-sensing per device, MAC address filtering, DFS support, VPN passthrough, CleanAir technology, reset button, 2T2R MIMO technology, ClientLink technology, Maximum Ratio Combining (MRC), radio resource management (RRM), cyclic shift diversity (CSD), MU-MIMO technology, Cisco Flexible Antenna Port technology, beamforming technology, packet aggregation A-MPDU, packet aggregation A-MSDU, High Density Experience (HDX)
Encryption Algorithm	LEAP, AES, TLS, PEAP, TTLS, WPA, WPA2
Authentication Method	X.509 certificates, Extensible Authentication Protocol (EAP)
Compliant Standards	IEEE 802.11, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac
Antenna
Antenna	Internal
Expansion / Connectivity
Interfaces	1 x 1000Base-T (PoE) - RJ-45 (WAN) ¦ 1 x - SFP (mini-GBIC) (WAN) ¦ 1 x console - RJ-45
Miscellaneous
Compliant Standards	EN 60950, ICES-003, IEC 60529 IP67, FCC Part 15.247, RSS-210, RSS-102, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, NEMA Type 4X, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, X.509, MIL-STD-810, EN 300 328, FCC OET Bulletin 65c, EN 301489-17, EN 301 489-1, AS/NZS 4268.2003, ANSI / IEEE 587 C62.41, NEMA 250-2008, EN 60068-2-5, UL 60950 Second Edition, CAN/CSA C22.2 No. 60950 Second Edition, IEC 60950 Second Edition, EN 60950 Second Edition, EN 301 893
Power
Power Over Ethernet (PoE) Supported	PoE+
Environmental Parameters
Min Operating Temperature	-40 °F
Max Operating Temperature	149 °F
