| Name: |
IE-4000-8T4G-E - Cisco ONE Industrial Ethernet (IE) 4000 Series Platform |
|
| Mfr. Part #: |
IE-4000-8T4G-E
|
|
| Condition: | New | |
| Authenticity: | Original Genuine OEM | |
| Availability: | In Stock | |
| Brand: | Cisco | |
| Price: | $3,312.80 | |
IE-4000-8T4G-E
Shipping:
Free ground shipping within United States up to 10LBS
᛫ Items in stock will arrive within the estimated delivery time.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.
᛫ Preordered items need to be negotiated for delivery time.
᛫ Compensation if delivery delayed.
Accepting POs:
We accept Purchase Orders from Government Agencies, Defense, Hospitals, Universities, Schools and Businesses.
-
Genuine Guarantee
-
Price Protection
-
Bulk Order Rebate
-
30 Day Return Policy
overview
specifications
resources
reviews
IE-4000-8T4G-E Overview
IE 4000 8 x RJ45 10/100M, 4 x 1G Combo, LAN Base IE-4000-8T4G-E
Overview
Cisco IE-4000-8T4G-E, Managed, L2, Fast Ethernet (10/100)
IE-4000-8T4G-E is an IE4000 series switch providing 8 x RJ45 10/100M, 4 x 1G Combo, and LAN Base. The IE 4000 Series is ideal for industrial Ethernet applications where hardened products are required, including manufacturing, energy, transportation, smart cities. The IE4000 has built-in SW image verification to ensure authenticity of the Cisco Software. With improved overall performance, greater bandwidth, advanced security features, and enhanced hardware, the Cisco IE 4000 Series complements the current industrial Ethernet portfolio of related Cisco industrial switches, such as the Cisco IE 2000 and IE 3000.
Quick Spec
Model | IE-4000-8T4G-E |
Total Ports | 12 |
GE combo uplinks (4G) | 4 GE combo uplink ports (Combo ports provide one copper and one fiber physical port and only one can be activated at a time.) |
RJ-45 copper ports (T) | 8 FE |
Default software | LAN Base feature set (Can be upgraded to IP Services at a fee.) |
Dimensions (H x W x D) | 6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm) |
Weight | 6.35 pounds (2.88 kg) |
Product Details
Figure 1 shows the front view of IE4000 8T switches.
Note:
① | 4 GE combo uplink ports |
② | 8 FE RJ-45 copper ports (T) |
③ | Alarm connector |
④ | Protective ground connection |
⑤ | Flash memory card slot |
⑥ | Power connector DC-B |
⑦ | Power connector DC-A |
⑧ | RJ-45 console port |
⑨ | USB mini-Type B (console) port (Use a screwdriver to remove the port cover and access the port.) |
Figure 2 shows the back view of IE4000 switches.
Supported Products
Model | Description |
Electronic IP SERVICES License for IE4000 Switches | |
Cisco ONE Foundation Perpetual - IE 4000/5000 | |
Cisco ONE Advanced Perpetual - IE 4000 | |
Cisco GLC-SX-MM-RGD 1000Mbps Multi-Mode Rugged SFP | |
1000BASE-BX10 SFP module for single-strand SMF, 1310-nm TX/1550-nm RX wavelength, single LC/PC connector | |
1000BASE-T SFP transceiver module for Category 5 copper wire | |
1000BASE-ZX SFP | |
1000BASE-BX SFP, 1310NM | |
1000BASE-LX/LH SFP (DOM) | |
Cisco GLC-ZX-SMD 1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM | |
Cisco GLC-SX-MMD 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM | |
100BASE-EX SFP (40km) | |
100BASE-BX10-U SFP |
Compare to Similar Items
Model | IE-4000-8T4G-E | |
Total Ports | 12 | 12 |
GE combo uplinks (4G) | 4 GE combo uplink ports | 4 GE combo uplink ports |
RJ-45 copper ports (T) | N/A | 8 FE |
SFP fiber ports (S) | 8 FE | N/A |
Default software | LAN Base feature set | LAN Base feature set |
Ordering Guide
IE-4000-8T4G-E - 4x GE Combo Uplinks, 8x FE RJ-45
- Managed L2
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 8
- MAC address table: 16000 entries
- Access Control List (ACL)
Summary Description
Cisco IE-4000-8T4G-E, Managed, L2, Fast Ethernet (10/100)
Need help with IE-4000-8T4G-E?
Get pricing, availability, lead time, and compatible options from our team. Chat with us live or email support@buyrouterswitch.com
Specification
IE-4000-8T4G-E Specification
IE-4000-8T4G-E Specification | |
Physical Specification | |
Total Ports | 12 |
GE combo uplinks (4G) | 4 GE combo uplink ports (Combo ports provide one copper and one fiber physical port and only one can be activated at a time.) |
RJ-45 copper ports (T) | 8 FE |
Default software | LAN Base feature set (Can be upgraded to IP Services at a fee.) |
Hardware | ● 1GB DRAM ● 128-MB onboard flash memory ● 1-GB removable SD flash memory card ● Mini-USB connector ● RJ-45 connector |
Alarm | Alarm I/O: two alarm inputs to detect dry contact open or closed, one alarm output relay |
Power Input | ● Redundant DC input voltage with operating range: nominal 9.6 to 60VDC ● Maximum DC input current: 3.7A |
Power consumption | 35W |
Dimensions (H x W x D) | 6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm) |
Weight | 6.35 pounds (2.88 kg) |
Switch performance and scalability | |
Forwarding rate | Line rate for all ports and all packet sizes |
Number of queues | 4 egress |
Unicast MAC addresses | 16,000 |
IGMP multicast groups | 1,000 |
Number of VLANs | 1,000 |
IPv4 MAC security ACEs | 1,000 with default TCAM Template |
NAT translation | Bidirectional, 128 unique subnet NAT translation entries, which can expand to tens of thousands of translated entries if designed properly |
